HighPoint Delivers the Industry's Most Comprehensive PCIe 3.0 NVMe RAID Controller Portfolio

HighPoint’s SSD7100 /7200 series PCIe 3.0 RAID controller are the industry's most versatile NVMe RAID storage solutions, and are cpable of delivering sustained transfer performance in excess of 14,000MB/s , with up to 120TB of storage capacity , in a single GPU sized device. SSD7100 series controllers can be easily installed into any modern system with a free PCIe 3.0/4.0 x16 or x8 slot, including compact workstations and servers that require a low-profile NVMe RAID solution.

HighPoint PCIe 3.0 NVMe RAID Controllers are compatible with all mainstream operating system platforms including Microsoft Windows 10 and Server 2019, macOS 10.15x, and current Linux distributions of centOS, Debian, and Ubuntu.

Learn More

  • Upcoming Products

    NVMe Product Catalog

A Paradigm shift for Compact System Acceleration

HighPoint PCIe 3.0 Series NVMe RAID Controllers pack the power of a 20+ SATA SSD RAID Array into a compact, stand-alone PCIe device that can be easily installed into nearly any type of workstation or server platform. This unconventional approach to NVMe storage represents a paradigm shift in the development of system acceleration solutions. Compact workstations and servers can now tackle complex projects and workflows that were once exclusive to specialized, large-scale hardware platforms.

Independent, Stand-Alone NVMe RAID Solutions For AMD & Intel Platforms

Supports PCIe 3.0 & 4.0 platforms, UEFI & Legacy BIOS

HighPoint PCIe 3.0 NVMe RAID Controllers are truly independent NVMe storage solutions, and were designed for easy integration into commercially available, Intel and AMD based high-performance desktops, workstations, and server platforms. Unlike most NVMe controllers or drive solutions featured in today’s marketplace, the SSD7100 Series can be used with nearly any system that has a free PCIe 3.0/4.0 x16 slot, and are fully compatible with Windows, macOS or Linux operating

Complete Fan Control

Low-Noise & Silent Operation for Sensitive Working Environments

HighPoint SSD7000 Series NVMe RAID controllers now feature Fan Control via the WebGUI Management software. Customers can adjust fan-speed using the SHI tab, and select from 3 speed settings. In addition, the fan can be completely powered off for silent operation. Administrators can monitor temperatures of each NVMe SSD using SHI, which can track the state of individual devices via SMART attributes, and adjust fan speeds to keep temperatures in check.

This feature is ideal for media and design applications that require low-noise or silent working environments, and platforms already equipped with robust cooling systems.

FnL AIC RAID Drives - Pre-Configured NVMe RAID Storage

Pre-Configured NVMe RAID Solution

FnL AIC Drives represent a new open platform for developing, building and integrating NVMe-based RAID storage solutions. FnL AIC Drives combine HighPoint SSD6200/7000/7500 series RAID controllers with select SSD’s from our NVMe Technology partners.

FnL AIC Drives take the pain and guesswork out of NVMe RAID storage. Years of storage expertise and technology partnerships with industry leading NVMe SSD vendors enables us to deliver blazing fast, pre-configured NVMe RAID storage for a wide range of applications, with little to no markup.
FnL will publish reports that document RAID transfer performance of NVMe SSD’s manufactured by our technology partners using a wide range of test suites and hardware/software environments. This platform is not limited to existing partnerships; FnL is open to any NVMe vendor interested in promoting the RAID performance of their SSD product lines.

ln addition, customers can request detailed test reports that document the compatibility and performance capabilities of each FnL AIC RAID Drive. Customers can specify the hardware and software platform, performance targets, and SSD drive preference. Learn More...

PCIe 3.0 NVMe RAID Controllers

M.2 Series

Model Bus Bandwidth Device Channels NVMe Form Factor / Port Type NVME RAID Level RAID Boot Single SSD Boot Cross Sync
SSD7140 x16 8x M.2 2242 / 2260 / 2280 Single, 0, 1, 1/0 n/a n/a
SSD7103 x16 4x M.2 2242 / 2260 / 2280 / 22110 Single, 0, 1, 1/0
SSD7104 x16 4x M.2 2242 / 2260 / 2280 / 22110 Single, 0, 1, 1/0 n/a
SSD7104F x16 4x M.2 2242 / 2260 / 2280 / 22110 Single, 0, 1, 1/0 n/a
SSD7101A-1 x16 4x M.2 2242 / 2260 / 2280 / 22110 Single, 0, 1, 1/0 n/a
SSD7204 x8 4x M.2 2242 / 2260 / 2280 / 22110 Single, 0, 1, 1/0 n/a n/a
SSD7202 x8 2x M.2 2242 / 2260 / 2280 Single, 0, 1
Note:Refer corresponding product specification for Boot RAID support under each OS.

U.2 Series

Model Bus Bandwidth Device Channels NVMe Form Factor / Port Type NVME RAID Level RAID Boot Single SSD Boot Cross Sync
SSD7180 x16 8x U.2 SFF-8643 Single, 0, 1, 1/0 n/a n/a n/a
SSD7184 x16 8x U.2 SFF-8643 / SFF-8644 Single, 0, 1, 1/0 n/a n/a n/a
SSD7120 x16 4x U.2 SFF-8643 Single, 0, 1, 1/0 n/a n/a

M.2 Series

SSD7140

NVMe | RAID | PCIe 3.0 x16

  • Up to 8x M.2 NVMe SSD's
  • 2242/2260/2280
  • RAID 0, 1, 1/0 & Single-Disk
  • Full-Height

SSD7103

NVMe | RAID | PCIe 3.0 x16

  • Up to 4x M2 NVMe SSD's
  • 2242/2260/2280 / 22110
  • RAID 0, 1, 1/0 & Single-Disk
  • Full-Height
SSD7104

NVMe | RAID | PCIe 3.0 x16

  • Up to 4x M2 NVMe SSD's
  • 2242/2260/2280 / 22110
  • RAID 0, 1, 1/0 & Single-Disk
  • Full-Height

SSD7101A-1

NVMe | RAID | PCIe 3.0 x16

  • Up to 4x M2 NVMe SSD's
  • 2242/2260/2280/22110
  • RAID 0, 1, 1/0 & Single-Disk
  • Full-Height

SSD7204

NVMe | RAID | PCIe 3.0 x8

  • Up to 4x M2 NVMe SSD's
  • 2242/2260/2280
  • RAID 0, 1, 1/0 & Single-Disk
  • Full-Height
SSD7202

NVMe | RAID | PCIe 3.0 x8

  • Up to 2x M2 NVMe SSD's
  • 2242/2260/2280
  • RAID 0, 1 & Single-Disk
  • Low-Profile

U.2 Series

SSD7180

NVMe | RAID | PCIe 3.0 x16

  • Up to 8x U.2 NVMe SSD's
  • 8x SFF-8643 connectors
  • RAID 0, 1, 1/0 & Single-Disk
  • Low-Profile

SSD7184

NVMe | RAID | PCIe 3.0 x16

  • Up to 8x U.2 NVMe SSD's
  • 4x SFF-8643 / 4x SFF-8644 connectors
  • RAID 0, 1, 1/0 & Single-Disk
  • Low-Profile
SSD7120

NVMe | RAID | PCIe 3.0 x16

  • Up to 4x U.2 NVMe SSD's
  • 4x SFF-8643 Ports
  • RAID 0, 1, 1/0 & Single-Disk
  • Low-Profile
