HighPoint NVMe Switch & RAID AIC/ Adapter Series
Delivers Gen5 x16 RAID Storage Performance From Desktop & Workstation to Cloud & Edge Servers
-
Dedicated Gen5 x16
-
Massive Storage Capacity
-
Low Latency
-
Reliable Connectivity
Up to 56GB/s
8x Gen4 or Gen5 Drives
2x Faster
than Gen4
Up to 8x M.2 Ports
8x Drive Expansion
Up to 4x MCIO Ports
32x Drive Expansion
Gen5 PCIe Switching Technology
HighPoint’s Rocket 7600 and Rocket 1600 Gen5 NVMe Switch & RAID AIC/Adapter series incorporates Broadcom’s state-of-the-art PCIe Switching technology to fully utilize x16 lanes of Gen5 host bandwidth, direct from the CPU. This unique architecture enables each AIC/Adapter to maximize transfer performance for up to 8 independent device channels, minimize latency, facilitate consistent, robust I/O throughput, and support as many as 32 NVMe devices via backplane connectivity.
More Gen5 Feature Solutions
Applicable Industries
.webp)
Gen5 NVMe Switch AICs & Adapters
Gen5 NVMe Switch AICs & Adapters
.webp)
Gen5 NVMe Switch AICs & Adapters
Feature | Description |
Bus Interface | PCIe 5.0 x16 |
Port Count | 8x NVMe Ports |
Connector Type | M.2 |
Device & Form factor | 2242, 2260, 2280 |
Cooling | Full-Length Aluminum Heatsink with cooling fan |
Ext. Power Connector | Yes (uses PCIe Standard 2x3 Power Connector) |
AIC Form factor | Full-Height, Single-Width |
Operating System Support | Compatible with all operating systems that have native NVMe driver support |
FRU | Yes (stores VPD data) |
Hardware Secure Boot | Yes |
Synthetic Hierarchy | Yes |
Rocket 1608A - PCIe Gen5 x16 to 8-M.2x4 NVMe Switch AIC
Gen5 NVMe Switch AICs & Adapters
.webp)
Gen5 NVMe Switch AICs & Adapters
Gen5 NVMe Switch AICs & Adapters
Gen5 NVMe Switch AICs & Adapters
Feature | Description |
Bus Interface | PCIe 5.0 x16 |
Port Count | 8x NVMe Ports |
Connector Type | MCIO (SFF-1016 8x) |
Device & Form factor | U.2/U.3, E3.S |
Cooling | Full-Length Aluminum Heatsink |
Adapter Form factor | LP-MD2, Single-Width |
Operating System Support | Compatible with all operating systems that have native NVMe driver support |
FRU | Yes (stores VPD data) |
Hardware Secure Boot | Yes |
Hot-Plug & Hot-Swap | Yes |
OOB Managament | Yes |
Synthetic Hierarchy | Yes |
Rocket 1628A - PCIe Gen5 x16 to 4-MCIOx8 NVMe Switch Adapter
Gen5 NVMe Switch AICs & Adapters
Gen5 NVMe Switch AICs & Adapters
Gen5 NVMe Switch AICs & Adapters
Feature | Description |
Bus Interface | PCIe 5.0 x16 |
Port Count | 8x NVMe Ports |
Connector Type | M.2 |
Device & Form factor | 2242, 2260, 2280 |
Cooling | Full-Length Aluminum Heatsink with cooling fan |
Ext. Power Connector | Yes (uses PCIe Standard 2x3 Power Connector) |
AIC Form factor | Full-Height, Single-Width |
Operating System Support | Windows & Linux |
FRU | Yes (stores VPD data) |
Hardware Secure Boot | Yes |
Synthetic Hierarchy | Yes |
RAID Support | Single, RAID 0, 1, 10 |
HighPoint Advanced Feature Suite | Yes |
Rocket 7608A - PCIe Gen5 x16 to 8-M.2x4 NVMe RAID AIC
Gen5 NVMe Switch AICs & Adapters
Gen5 NVMe Switch AICs & Adapters
Gen5 NVMe Switch AICs & Adapters
Feature | Description |
Bus Interface | PCIe 5.0 x16 |
Port Count | 8x NVMe Ports |
Connector Type | MCIO (SFF-1016 8x) |
Device & Form factor | U.2/U.3, E3.S |
Cooling | Full-Length Aluminum Heatsink |
Adapter Form factor | LP-MD2, Single-Width |
Operating System Support | Windows & Linux |
FRU | Yes (stores VPD data) |
Hardware Secure Boot | Yes |
Hot-Plug & Hot-Swap | Yes |
OOB Managament | Yes |
Synthetic Hierarchy | Yes |
RAID Support | Single, RAID 0, 1, 10 |
HighPoint Advanced Feature Suite | Yes |
Rocket 7628A - PCIe Gen5 x16 to 4-MCIOx8 NVMe RAID Adapter
